Model No.
SEP8660-40, SEP8660-50, SEP8660-60, SEP8660-70
Product Description
This silicone sealing strip is a modified silicone EPDM. It features high temperature resistance and good weatherproof property, as well as the superior mechanical properties inherited from EPDM. This silicone material is used to make sealing strips for automobile engines and doors.
Storage
Keep sealed and store under cool, dark conditions.
Usage
Mix it with appropriate peroxide according to specific proportion and then apply extrusion molding.
Packing
The silicone sealing strip for automobile engines and doors is packed in 20kg cartons.
Typical Property
Properties | Test method | Unit | SEP8660-40 | SEP8660-50 | SEP8660-60 | SEP8660-70 |
Shore A hardness | D2204 | °A | 40 | 50 | 60 | 70 |
Tensile strength | D412 | Mpa | 8.0 | 9.0 | 9.0 | 8.5 |
Tear strength | D624B | KN/m | 15.0 | 18.0 | 17.0 | 15.0 |
Elongation at break | D412 | % | 600 | 550 | 450 | 380 |
Compression set | DIN53517 22hours@175℃ | % | 25.0 | 24.0 | 25.0 | 26.0 |
Curing condition | C-2 1.50% 130℃x 10 mins |
Note: The above technical properties are for reference only. For detailed molding conditions, please contact us directly.
As an experienced silicone sealing strip for automobile engine and door manufacturer and supplier based in China, SQUARE Silicone Materials Company provides a wide range of silicone materials for different applications. Besides silicone sealing strip for automobile engines and doors, we also provide additive and high voltage insulators. They are commonly used in such fields as electronic products, electric power, medical instruments, baby products, kitchenware, automobiles, textiles, mechanical engineering, and other consumer products.
For any inquires or orders, please contact us directly! We are confident that our silicone materials will satisfy your needs.
