Model No.
LIM6910-40A/B, LIM6909-40A/B
Product Description
This series of products is referred to as bi-component platinum catalyzed semitransparent liquid silicone rubber. These silicone rubbers feature high liquidity, good elastic resilience, high tear strength, stable shrinkage rate, etc. They offer good resistance to extreme temperatures, being able to operate normally from -60℃ to 250℃. With excellent properties, our silicone rubber is used for inject molding computer keyboard linings.
Storage
The unopened product will have a shelf life of 180 days at a maximum room temperature of 27℃. Once open, keep sealed and store in cool and dry place, and consume within seven days.
Usage
Use a static mixer to mix the two components, A and B, with a ratio of 1:1. Feed the mixture directly into an injection molding machine. The AB mixture can be vulcanized in a few seconds.
Packing
The silicone rubber for computer keyboard is packed in 20kg or 200kg barrels.
Typical Property
Properties | Test method | Unit | LIM6910-40A/B | LIM6909-40A/B |
Appearance | Transparent | Tanslucent | ||
Viscosity | DIN53019 | mPa.s | 85000 | 60000 |
Specific gravity | D792 | 1.08 | 1.08 | |
Shore A hardness | D2204 | °A | 43 | 43 |
Tensile strength | D412 | MPa | 5.0 | 5.0 |
Tear strength | D624B | KN/m | 12.0 | 15.0 |
Elongation at break | D412 | % | 300 | 300 |
Tensile set | D412 DIE C | % | 0.68 | 0.68 |
Linear shrinkage | JISK 6301 | % | 1.5 | 1.5 |
The silicone rubber properties are as the flowing: mixing arts A and B at the mixing ratio 1: 1, and then molding under 150℃X10 minutes |
Note: The above technical properties are for reference only. For detailed molding conditions, please contact us directly.
